SPECIFICATIONS - LMS HUNSLET 150hp SHUNTER
| POWER TYPE | Diesel Mechanical |
| BUILDER | Hunslet Engine Co. Leeds |
| WHEEL ARRANGEMENT | 0-6-0 |
| WHEELBASE | LMS 7051- 8 ft
LMS 7052 - 9ft LMS 7053 - 9ft |
| DIMENSIONS | LMS 7051 - L.23ft 2in - W.8ft 2in - H.11ft 4.75in
LMS 7052 - L.24ft 8.5in - W. 8ft 3in - H.12ft 1in LMS 7053 - L.25ft 0.75in- W. 8ft 3in - H.12ft 0.9in |
| WEIGHT | LMS 7051-21 tons 8cwt
LMS 7052 - 25.5 tons LMS 7053 - 25.4tons |
| WHEEL DIAMETER | LMS 7051 3ft
LMS 7052- 3ft 4in LMS 7053- 3ft 4in |
| ENGINE | LMS 7051 MAN WV16/22
then McLaren Ricardo MR6
LMS 7052 - Mclaren Benz 8MDB LMS 7053 -Brotherhood-Ricardo RZ5 |
| TRACTIVE EFFORT | LMS 7051 -10520 lbf
LMS 7052 - 13200 lbf LMS 7053 - 12375 lbf |
| TRAIN BRAKES | None |
| BRAKE FORCE | |
| FUEL CAPACITY | Gals |
| POWER OUTPUT | LMS 7051 - 150hp / 132hp
LMS 7052 - 150hp LMS 7053- 150hp |
| MAX SPEED | LMS 7051- 30mph
LMS 7052- 8mph LMS 7053 - 14mph |
| BUILT / WITHDRAWN | 1932-34 / 1942-45 | No. BUILT | 1 of each |
RETURN TO LIST OF CLASS TYPES
RETURN TO LIST OF LOCO NUMBERS
LOCOMOTIVES IN CLASS
| REGION OR CLASS |
REGION No. |
1948 No. | 1957 No. | TOPS No. | RENUMBER | STATUS | LOCO FACTS |
|---|---|---|---|---|---|---|---|
| LMS | 7051 | Preservation | LMS-7051 | ||||
| LMS | 7052 | Scrapped | LMS-7052 | ||||
| LMS | 7053 | -- | Scrapped | LMS-7053 |
