SPECIFICATIONS - LMS PAXMAN 400hp SHUNTER
| POWER TYPE | Diesel Hydraulic |
| BUILDER | LMS Derby |
| WHEEL ARRANGEMENT | 0-6-0 |
| WHEELBASE | 15ft 8in |
| DIMENSIONS | L.30ft 3.75in - W.8ft 7.5in - H.12ft 9in |
| WEIGHT | 46ton |
| WHEEL DIAMETER | 4ft 7in |
| ENGINE | Paxman 4 stroke |
| TRAIN BRAKES | Vacuum |
| BRAKE FORCE | |
| FUEL CAPACITY | 140 Gals |
| POWER OUTPUT | 400hp |
| TRACTIVE EFFORT | 21000lb |
| MAX SPEED | 25mph |
| BUILT / WITHDRAWN | 1934/1939 | No. BUILT | 1 |
RETURN TO LIST OF CLASS TYPES
RETURN TO LIST OF LOCO NUMBERS
LOCOMOTIVES IN CLASS
| REGION OR CLASS |
REGION No. |
1948 No. | 1957 No. | TOPS No. | RENUMBER | STATUS | LOCO FACTS |
|---|---|---|---|---|---|---|---|
| LMS | 1831 | Scrapped | LMS-1831 |
