SPECIFICATIONS
| POWER TYPE | Diesel Electric |
| BUILDER | Southern Railway Ashford Works |
| WHEEL ARRANGEMENT | 0-6-0 |
| WHEELBASE | -11ft 6in |
| DIMENSIONS | L.30ft 3.5in - W.8ft 5.25in - H.12ft 9in |
| WEIGHT | 55.5 ton |
| WHEEL DIAMETER | 4ft 6in |
| ENGINE | English Electric 6K |
| TRAIN BRAKES | None |
| BRAKE FORCE | 29 tonnes |
| FUEL CAPACITY | 490Gals |
| POWER OUTPUT | 350 hp |
| TRACTIVE EFFORT | 30000lbs |
| MAX SPEED | 30 mph |
| BUILT / WITHDRAWN | 1937/1964 | No. BUILT | 3 |
RETURN TO LIST OF CLASS TYPES
RETURN TO LIST OF LOCO NUMBERS
LOCOMOTIVES IN CLASS
| REGION OR CLASS |
REGION No. |
1948 No. | 1957 No. | TOPS No. | RENUMBER | STATUS | LOCO FACTS |
|---|---|---|---|---|---|---|---|
| D3/12 | S1 | 15201 | Scrapped | 15201 | |||
| D3/12 | S2 | 15202 | Scrapped | 15202 | |||
| D3/12 | S3 | 15203 | Scrapped | 15203 |
