SPECIFICATIONS
| POWER TYPE | Diesel /Electric/Battery |
| BUILDER | Stadler, Valencia, Spain |
| WHEEL ARRANGEMENT | Bo-Bo |
| WHEELBASE | |
| DIMENSIONS | LENGTH 67.25ft/ WIDTH 8.82ft |
| WEIGHT | 86 tonnes |
| WHEEL DIAMETER | |
| ENGINE | Caterpillar C32 12 Cylinder |
| TRAIN BRAKES | Air,regenerative & electro-pneumatic |
| BRAKE FORCE | 73 tonnes |
| FUEL CAPACITY | 3600 ltr |
| POWER OUTPUT | AC ELECTRIC 6200hp. / DIESEL ENGINE 1200hp / BATTERY PACK 540hp |
| TRACTIVE EFFORT | 65200lb |
| MAX SPEED | 110mph |
| BUILT / WITHDRAWN | 2021-24 / - | No. BUILT | 10 |
RETURN TO LIST OF CLASS TYPES
RETURN TO LIST OF LOCO NUMBERS
LOCOMOTIVES IN CLASS
| REGION OR CLASS |
REGION No. |
1948 No. | 1957 No. | TOPS No. | RENUMBER | STATUS | LOCO FACTS |
|---|---|---|---|---|---|---|---|
| 93 | 93001 | Commercial | 93001 | ||||
| 93 | 93002 | Commercial | 93002 | ||||
| 93 | 93003 | Commercial | 93003 | ||||
| 93 | 93004 | Commercial | 93004 | ||||
| 93 | 93005 | Commercial | 93005 | ||||
| 93 | 93006 | Commercial | 93006 | ||||
| 93 | 93007 | Commercial | 93007 | ||||
| 93 | 93008 | Commercial | 93008 | ||||
| 93 | 93009 | Commercial | 93009 | ||||
| 93 | 93010 | Commercial | 93010 |
