CLASS TYPE 30-31

An example of Diesel Class 30-31

ORIGINAL SPECIFICATION CLASS 30

POWER TYPE	Diesel Electric
BUILDER	Brush
WHEEL ARRANGEMENT	A1A-A1A
WHEELBASE	42 ft 10in
DIMENSIONS	L. -56ft 9in W. - 8ft 9in H.-12ft 7in
WEIGHT	107-111 tonnes
WHEEL DIAMETER	3ft 7in
ENGINE	Mirrlees JVS12T
TRACTIVE EFFORT	42,000lbs
TRAIN BRAKES	Vacuum
BRAKE FORCE	49 tonnes
FUEL CAPACITY	650 gals
POWER OUTPUT	1250hp
MAX SPEED	75mph
BUILT/ WITHDRAWN	1957-62 / 1975-2017
No. BUILT	263

1965-1969 All Locomotives Re-Engined with English Electric 12SVT, and became Class 31 with the following sub-classes

SUB CLASSES

31/0	Electro Magnetic Control Power Output now 1470hp
31/1	Standard Locomotives with Electro Pneumatic control>BR> Fuel Capacity now 530 gal Speed 80/90mph
31/4	Electric Train Heating Equipment Speed 90mph
31/5	Isolated ETS Equipment
31/6	through ETS control cables Speed now 60mph

RETURN TO LIST OF CLASS TYPES

RETURN TO LIST OF LOCO NUMBERS

LOCOMOTIVES IN CLASS

`

REGION
OR CLASS REGION
No. 1948 No. 1957 No. TOPS No. RENUMBER STATUS LOCO FACTS

31/0 D5500 31018 Preservation D5500 - 31018

31/0 D5501 31001 Scrapped D5501 - 31001

31/0 D5502 31002 Scrapped D5502 - 31002

31/0 D5503 31003 Scrapped D5503 - 31003

31/0 D5504 31004 Scrapped D5504 - 31004

31/0 D5505 31005 Scrapped D5505 - 31005

31/0 D5506 31006 Scrapped D5506 - 31006

31/0 D5507 31007 Scrapped D5507 - 31007

31/0 D5508 31008 Scrapped D5508 - 31008

31/0 D5509 31009 Scrapped D5509 - 31009

31/0 D5510 31010 Scrapped D5510 - 31010

31/0 D5511 31011 Scrapped D5511 - 31011

31/0 D5512 31012 Scrapped D5512 - 31012

31/0 D5513 31013 Scrapped D5513 - 31013

31/0 D5514 31014 Scrapped D5514 - 31014

31/0 D5515 31015 Scrapped D5515 - 31015

31/0 D5516 31016 Scrapped D5516 - 31016

31/0 D5517 31017 Scrapped D5517 - 31017

31/1 D5518 31101 Preservation D5518 - 31101

31/0 D5519 31019 Scrapped D5519 - 31019

31/1 D5520 31102 Scrapped D5520 - 31102

31/1 D5521 31103 Scrapped D5521 - 31103

31/4 D5522 31418 Preservation D5522 - 31418

31/1 D5523 31105 Preservation D5523 - 31105

31/1 D5524 31106 Scrapped D5524 - 31106

31/1 D5525 31107 Scrapped D5525 - 31107

31/1 D5526 31108 Preservation D5526 - 31108

31/1 D5527 31109 Scrapped D5527 - 31109

31/1 D5528 31110 Scrapped D5528 - 31110

31/1 D5529 31111 Scrapped D5529 - 31111

31/1 D5530 31112 Scrapped D5530 - 31112

31/1 D5531 31113 Scrapped D5531 - 31113

31/5 D5532 31114 31453
31553 Scrapped D5532 - 31114 - 31453 - 31553

31/4 D5533 31115 31466 Preservation D5533 - 31115 - 31466

31/1 D5534 31116 Scrapped D5534 - 31116

31/1 D5535 31117 Scrapped D5535 - 31117

31/1 D5536 31118 Scrapped D5536 - 31118

31/1 D5537 31119 Preservation D5537 - 31119

31/1 D5538 31120 Scrapped D5538 - 31120

31/1 D5539 31121 Scrapped D5539 - 31121

31/1 D5540 31122 Scrapped D5540 - 31122

31/1 D5541 31123 Scrapped D5541 - 31123

31/1 D5542 31124 Scrapped D5542 - 31124

31/1 D5543 31125 Scrapped D5543 - 31125

31/1 D5544 31126 Scrapped D5544 - 31126

31/1 D5545 31127 Scrapped D5544 - 31127

31/1 D5546 31128 Preservation D5546 - 31128

31/4 D5547 31129 31461 Preservation D5547 - 31129 - 31461

31/1 D5548 31130 Preservation D5548 - 31130

31/1 D5549 31131 Scrapped D5549 - 31131

31/1 D5550 31132 Scrapped D5550 - 31132

31/4 D5551 31133 31450 Scrapped D5551 - 31133 - 31450

31/1 D5552 31134 Scrapped D5552 - 31134

31/1 D5553 31135 Scrapped D5553 - 31135

31/1 D5554 31136 Scrapped D5554 - 31136

31/4 D5555 31137 31544
31444 Scrapped D5555 - 31137 - 31544 - 31444

31/1 D5556 31138 Scrapped D5556 - 31138

31/5 D5557 31139 31438
31538 Preservation D5557 - 31139 - 31438 - 31538

31/4 D5558 31140 31421 Scrapped D5558 - 31140 - 31421

31/1 D5559 31141 Scrapped D5559 - 31141

31/1 D5560 31142 Scrapped D5560 - 31142

31/1 D5561 31143 Scrapped D5561 - 31143

31/1 D5562 31144 Scrapped D5562 - 31144

31/1 D5563 31145 Scrapped D5563 - 31145

31/1 D5564 31146 Scrapped D5564 - 31146

31/1 D5565 31147 Scrapped D5565 - 31147

31/5 D5566 31148 31448
31548 Scrapped D5566 - 31148 - 31448 - 31548

31/1 D5567 31149 Scrapped D5567 - 31149

31/1 D5568 31150 Scrapped D5568 - 31150

31/4 D5569 31151 31436 Scrapped D5569 - 31151 - 31436

31/1 D5570 31152 Scrapped D5570 - 31152

31/4 D5571 31153 31432 Scrapped D5571 - 31153 - 31432

31/1 D5572 31154 Scrapped D5572 - 31154

31/1 D5573 31155 Scrapped D5573 - 31155
31/1 D5574 31156 Scrapped D5574 - 31156

31/5 D5575 31157 31424
31524 Scrapped D5575 - 31157 - 31424 - 31524

31/1 D5576 31158 Scrapped D5576 - 31158

31/1 D5577 31159 Scrapped D5577 - 31159

31/1 D5578 31160 Scrapped D5578 - 31160

31/4 D5579 31161 31400 Scrapped D5579 - 31161 - 31400

31/1 D5580 31162 Preservation D5580 - 31162

31/1 D5581 31163 Preservation D5581 - 31163

31/1 D5582 31164 Scrapped D5582 - 31164

31/1 D5583 31165 Scrapped D5583 - 31165

31/1 D5584 31166 Scrapped D5584 - 31166

31/1 D5585 31167 Scrapped D5585 - 31167

31/1 D5586 31168 Scrapped D5586 - 31168

31/4 D5587 31169 31457 Scrapped D5587 - 31169 - 31457

31/1 D5588 31170 Scrapped D5588 - 31170

31/4 D5589 31401 Scrapped D5589 - 31401

31/1 D5590 31171 Scrapped D5590 - 31171

31/4 D5591 31172 31420 Scrapped D5591 - 31172 - 31420

31/4 D5592 31402 Scrapped D5592 - 31402

31/1 D5593 31173 Scrapped D5593 - 31173

31/1 D5594 31174 Scrapped D5594 - 31174

31/1 D5595 31175 Scrapped D5595 - 31175

31/4 D5596 31403 Scrapped D5596 - 31403
31/1 D5597 31176 Scrapped D5597 - 31176

31/4 D5598 31177 31443 Scrapped D5598 - 31177 - 31443

31/1 D5599 31178 Scrapped D5599 - 31178

31/4 D5600 31179 31435 Preservation D5600 - 31179 - 31435

31/1 D5601 31180 Scrapped D5601 - 31180

31/1 D5602 31181 Scrapped D5602 - 31181

31/4 D5603 31182 31537
31437 Scrapped D5603 - 31182 - 31537 - 31437

31/1 D5604 31183 Scrapped D5604 - 31183

31/4 D5605 31404 Scrapped D5605 - 31404

31/4 D5606 31405 Scrapped D5606 - 31405

31/1 D5607 31184 Scrapped D5607 - 31184

31/1 D5608 31185 Scrapped D5608 - 31185

31/6 D5609 31186 31601 Preservation D5609 - 31186 - 31601

31/1 D5610 31187 Scrapped D5610 - 31187

31/1 D5611 31188 Scrapped D5611 - 31188

31/1 D5612 31189 Scrapped D5612 - 31189

31/1 D5613 31190 Preservation D5613 - 31190

31/6 D5614 31191 31602 Scrapped D5614 - 31191 - 31602

31/1 D5615 31192 Scrapped D5615 - 31192

31/4 D5616 31406 Scrapped D5616 - 31406

31/4 D5617 31193 31526
31426 Scrapped D5617 - 31193 - 31526 - 31426

31/4 D5618 31194 31427 Scrapped D5618 - 31194 - 31427

31/1 D5619 31195 Scrapped D5619 - 31195

31/1 D5620 31196 Scrapped D5620 - 31196

31/4 D5621 31197 31423 Scrapped D5621 - 31197 - 31423

31/1 D5622 31198 Scrapped D5622 - 31198

31/1 D5623 31199 Scrapped D5623 - 31199

31/1 D5624 31200 Scrapped D5624 - 31200

31/1 D5625 31201 Scrapped D5625 - 31201

31/1 D5626 31202 Scrapped D5626 - 31202

31/1 D5627 31203 Preservation D5627 - 31203

31/4 D5628 31204 31440 Scrapped D5628 - 31204 - 31440

31/1 D5629 31205 Scrapped D5629 - 31205

31/1 D5630 31206 Preservation D5630 - 31206

31/1 D5631 31207 Preservation D5631 - 31207

31/1 D5632 31208 Scrapped D5632 - 31208

31/1 D5633 31209 Scrapped D5633 - 31209

31/1 D5634 31210 Preservation D5634 - 31210

31/4 D5635 31211 31428 Scrapped D5635 - 31211 - 31428

31/1 D5636 31212 Scrapped D5636 - 31212

31/4 D5637 31213 31565
31465 Preservation D5637 - 31213 - 31565 - 31465

31/1 D5638 31214 Scrapped D5638 - 31214

31/1 D5639 31215 Scrapped D5639 - 31215

31/4 D5640 31507 31407 Scrapped D5640 - 31507 - 31407

31/4 D5641 31216 31467 Scrapped D5641 - 31216 - 31467

31/1 D5642 31217 Scrapped D5642 - 31217

31/1 D5643 31218 Scrapped D5643 - 31218

31/1 D5644 31219 Scrapped D5644 - 31219

31/5 D5645 31220 31441
31541 Scrapped D5645 - 31220 - 31441 - 31541

31/4 D5646 31408 Scrapped D5646 - 31408

31/1 D5647 31221 Scrapped D5647 - 31221

31/1 D5648 31222 Scrapped D5648 - 31222

31/1 D5649 31223 Scrapped D5649 - 31223

31/1 D5650 31224 Scrapped D5650 - 31224

31/1 D5651 31225 Scrapped D5651 - 31225

31/1 D5652 31226 Scrapped D5652 - 312206

31/1 D5653 31227 Scrapped D5653 - 31227

31/4 D5654 31228 31554
31454 Preservation D5654 - 31228 - 31554 - 31454

31/1 D5655 31229 Scrapped D5655 - 31229

31/4 D5656 31409 Scrapped D5656 - 31409

31/1 D5657 31230 Scrapped D5657 - 31230

31/1 D5658 31231 Scrapped D5658 - 31231

31/1 D5659 31232 Scrapped D5659 - 31232

31/1 D5660 31233 Preservation D5660 - 31233

31/1 D5661 31234 Scrapped D5661 - 31234

31/1 D5662 31235 Preservation D5662 - 31235

31/4 D5663 31236 31533
31433 Scrapped D5663 - 31236 - 31533 - 31433

31/1 D5664 31237 Scrapped D5664 - 31237

31/1 D5665 31238 Scrapped D5665 - 31238

31/4 D5666 31239 31439 Scrapped D5666 - 31239 - 31439

31/1 D5667 31240 Scrapped D5667 - 31240

31/1 D5668 31241 Scrapped D5668 - 31241

31/4 D5669 31410 Scrapped D5669 - 31410

31/1 D5670 31242 Scrapped D5670 - 31242

31/1 D5671 31243 Scrapped D5671 - 31243

31/1 D5672 31244 Scrapped D5672 - 31244

31/1 D5673 31245 Scrapped D5673 - 31245

31/4 D5674 31246 31555
31455 Scrapped D5674 - 31246 - 31555- 31455

31/1 D5675 31247 Scrapped D5675 - 31247

31/1 D5676 31248 Scrapped D5676 - 31248

31/1 D5677 31249 Scrapped D5677 - 31249

31/1 D5678 31250 Scrapped D5678 - 31250

31/4 D5679 31251 31442 Scrapped D5679 - 31251 - 31442

31/1 D5680 31252 Scrapped D5680 - 31252

31/5 D5681 31253 31431
31531 Scrapped D5681 - 31253 - 31431 - 31531

31/1 D5682 31254 Scrapped D5682 - 31254

31/1 D5683 31255 Preservation D5683 - 31255

31/4 D5684 31256 31459 Preservation D5684 - 31256 - 31459

31/1 D5685 31257 Scrapped D5685 - 31257

31/4 D5686 31258 31434 Scrapped D5686 - 31258 - 31434

31/1 D5687 31259 Scrapped D5687 - 31259

31/1 D5688 31260 Scrapped D5688 - 31260

31/1 D5689 31261 Scrapped D5689 - 31261

31/1 D5690 31262 Scrapped D5690 - 31262

31/4 D5691 31511 31411 Scrapped D5691 - 31511 - 31411

31/4 D5692 31512 31412 Scrapped D5692 - 31512 - 31412

31/1 D5693 31263 Scrapped D5693 - 31263

31/1 D5694 31264 Scrapped D5694 - 31264

31/5 D5695 31265 31430
31530 Preservation D5695 - 31265 - 31430 - 31530

31/4 D5696 31266 31460 Scrapped D5696 - 31266 - 31460

31/5 D5697 31419 31519 Scrapped D5697 - 31419 - 31519

31/1 D5698 31268 Scrapped D5698 - 31268

31/4 D5699 31269 31429 Scrapped D5699 - 31269 - 31429

31/1 D5800 31270 Preservation D5800 - 31270

31/1 D5801 31271 Preservation D5801 - 31271

31/1 D5802 31272 Scrapped D5802 - 31272

31/1 D5803 31273 Scrapped D5803 - 31273

31/4 D5804 31274 31425 Scrapped D5804 - 31274 - 31425

31/1 D5805 31275 Scrapped D5805 - 31275

31/1 D5806 31276 Scrapped D5806 - 31276

31/5 D5807 31277 31469
31569 Scrapped D5807 - 31277 - 31469 - 31569

31/1 D5808 31278 Scrapped D5808 - 31278

31/4 D5809 31279 31552
31452 Preservation D5809 - 31279 - 31552 - 31452

31/1 D5810 31280 Scrapped D5810 - 31280

31/1 D5811 31281 Scrapped D5811 - 31281

31/4 D5812 31413 Scrapped D5812 - 31413

31/1 D5813 31282 Scrapped D5813 - 31282

31/5 D5814 31414 31514 Preservation D5814 - 31414 - 31514

31/1 D5815 31283 Scrapped D5815 - 31283

31/1 D5816 31284 Scrapped D5816 - 31284

31/1 D5817 31285 Preservation D5817 - 31285

31/1 D5818 31286 Scrapped D5818 - 31286

31/1 D5819 31287 Scrapped D5819 - 31287

31/1 D5820 31288 Scrapped D5820 - 31288

31/1 D5821 31289 Preservation D5821 - 31289

31/1 D5822 31290 Scrapped D5822 - 31290

31/5 D5823 31291 31456
31556 Scrapped D5823 - 31291 - 31456 - 31556

31/4 D5824 31415 Scrapped D5824 - 31415

31/1 D5825 31292 Scrapped D5825 - 31292

31/1 D5826 31293 Scrapped D5826 - 31293

31/1 D5827 31294 Scrapped D5827 - 31294

31/5 D5828 31295 31447
31547 Scrapped D5828 - 31295 - 31447 - 31547

31/1 D5829 31296 Scrapped D5829 - 31296

31/5 D5830 31297 31463
31563 Preservation D5830 - 31297 - 31463 - 31563

31/1 D5831 31298 Scrapped D5831 - 31298

31/1 D5832 31299 Scrapped D5832 - 31299

31/5 D5833 31300 31445
31545 Scrapped D5833 - 31300 - 31445 - 31545

31/1 D5834 31301 Scrapped D5834 - 31301

31/1 D5835 31302 Scrapped D5835 - 31302

31/5 D5836 31303 31458
31558 Scrapped D5836 - 31303 - 31458 - 31558

31/1 D5837 31304 Scrapped D5837 - 31304

31/1 D5838 31305 Scrapped D5838 - 31305

31/1 D5839 31306 Scrapped D5839 - 31306

31/5 D5840 31307 31449
31549 Scrapped D5840 - 31307 - 31449 - 31549

31/1 D5841 31308 Scrapped D5841 - 31308

31/5 D5842 31416 31516 Scrapped D5842 - 31416 - 31516

31/1 D5843 31309 Scrapped D5843 - 31309

31/4 D5844 31310 31522
31422 Scrapped D5844 - 31310 - 31522 - 31422

31/1 D5845 31311 Scrapped D5845 - 31311

31/1 D5846 31312 Scrapped D5846 - 31312

31/1 D5847 31313 Scrapped D5847 - 31313

31/1 D5848 31314 Scrapped D5848 - 31314

31/4 D5849 31315 31462 Scrapped D5849 - 31315 - 31462

31/5 D5850 31316 31446
31546 Scrapped D5850 - 31316 - 31446 - 31546

31/1 D5851 31317 Scrapped D5851 - 31317

31/5 D5852 31318 31451
31551 Scrapped D5852 - 31318 - 31451 - 31551

31/1 D5853 31319 Scrapped D5853 - 31319

31/1 D5854 31320 Scrapped D5854 - 31320

31/4 D5855 31321 31568
31468 Scrapped D5855 - 31321 - 31568 - 31468

31/4 D5856 31417 Scrapped D5856 - 31417

31/1 D5857 31322 Scrapped D5857 - 31322

31/1 D5858 31323 Scrapped D5858 - 31328

31/1 D5859 31324 Scrapped D5859 - 31324

31/4 D5860 31325 31464 Scrapped D5860 - 31325 - 31464

31/1 D5861 31326 31970 Scrapped D5861 - 31326 - 31970

31/1 D5862 31327 Preservation D5862 - 31327

REGION OR CLASS	1957 No.	TOPS No.	RENUMBER	STATUS	LOCO FACTS
31/0	D5500	31018		Preservation	D5500 - 31018
31/0	D5501	31001		Scrapped	D5501 - 31001
31/0	D5502	31002		Scrapped	D5502 - 31002
31/0	D5503	31003		Scrapped	D5503 - 31003
31/0	D5504	31004		Scrapped	D5504 - 31004
31/0	D5505	31005		Scrapped	D5505 - 31005
31/0	D5506	31006		Scrapped	D5506 - 31006
31/0	D5507	31007		Scrapped	D5507 - 31007
31/0	D5508	31008		Scrapped	D5508 - 31008
31/0	D5509	31009		Scrapped	D5509 - 31009
31/0	D5510	31010		Scrapped	D5510 - 31010
31/0	D5511	31011		Scrapped	D5511 - 31011
31/0	D5512	31012		Scrapped	D5512 - 31012
31/0	D5513	31013		Scrapped	D5513 - 31013
31/0	D5514	31014		Scrapped	D5514 - 31014
31/0	D5515	31015		Scrapped	D5515 - 31015
31/0	D5516	31016		Scrapped	D5516 - 31016
31/0	D5517	31017		Scrapped	D5517 - 31017
31/1	D5518	31101		Preservation	D5518 - 31101
31/0	D5519	31019		Scrapped	D5519 - 31019
31/1	D5520	31102		Scrapped	D5520 - 31102
31/1	D5521	31103		Scrapped	D5521 - 31103
31/4	D5522	31418		Preservation	D5522 - 31418
31/1	D5523	31105		Preservation	D5523 - 31105
31/1	D5524	31106		Scrapped	D5524 - 31106
31/1	D5525	31107		Scrapped	D5525 - 31107
31/1	D5526	31108		Preservation	D5526 - 31108
31/1	D5527	31109		Scrapped	D5527 - 31109
31/1	D5528	31110		Scrapped	D5528 - 31110
31/1	D5529	31111		Scrapped	D5529 - 31111
31/1	D5530	31112		Scrapped	D5530 - 31112
31/1	D5531	31113		Scrapped	D5531 - 31113
31/5	D5532	31114	31453 31553	Scrapped	D5532 - 31114 - 31453 - 31553
31/4	D5533	31115	31466	Preservation	D5533 - 31115 - 31466
31/1	D5534	31116		Scrapped	D5534 - 31116
31/1	D5535	31117		Scrapped	D5535 - 31117
31/1	D5536	31118		Scrapped	D5536 - 31118
31/1	D5537	31119		Preservation	D5537 - 31119
31/1	D5538	31120		Scrapped	D5538 - 31120
31/1	D5539	31121		Scrapped	D5539 - 31121
31/1	D5540	31122		Scrapped	D5540 - 31122
31/1	D5541	31123		Scrapped	D5541 - 31123
31/1	D5542	31124		Scrapped	D5542 - 31124
31/1	D5543	31125		Scrapped	D5543 - 31125
31/1	D5544	31126		Scrapped	D5544 - 31126
31/1	D5545	31127		Scrapped	D5544 - 31127
31/1	D5546	31128		Preservation	D5546 - 31128
31/4	D5547	31129	31461	Preservation	D5547 - 31129 - 31461
31/1	D5548	31130		Preservation	D5548 - 31130
31/1	D5549	31131		Scrapped	D5549 - 31131
31/1	D5550	31132		Scrapped	D5550 - 31132
31/4	D5551	31133	31450	Scrapped	D5551 - 31133 - 31450
31/1	D5552	31134		Scrapped	D5552 - 31134
31/1	D5553	31135		Scrapped	D5553 - 31135
31/1	D5554	31136		Scrapped	D5554 - 31136
31/4	D5555	31137	31544 31444	Scrapped	D5555 - 31137 - 31544 - 31444
31/1	D5556	31138		Scrapped	D5556 - 31138
31/5	D5557	31139	31438 31538	Preservation	D5557 - 31139 - 31438 - 31538
31/4	D5558	31140	31421	Scrapped	D5558 - 31140 - 31421
31/1	D5559	31141		Scrapped	D5559 - 31141
31/1	D5560	31142		Scrapped	D5560 - 31142
31/1	D5561	31143		Scrapped	D5561 - 31143
31/1	D5562	31144		Scrapped	D5562 - 31144
31/1	D5563	31145		Scrapped	D5563 - 31145
31/1	D5564	31146		Scrapped	D5564 - 31146
31/1	D5565	31147		Scrapped	D5565 - 31147
31/5	D5566	31148	31448 31548	Scrapped	D5566 - 31148 - 31448 - 31548
31/1	D5567	31149		Scrapped	D5567 - 31149
31/1	D5568	31150		Scrapped	D5568 - 31150
31/4	D5569	31151	31436	Scrapped	D5569 - 31151 - 31436
31/1	D5570	31152		Scrapped	D5570 - 31152
31/4	D5571	31153	31432	Scrapped	D5571 - 31153 - 31432
31/1	D5572	31154		Scrapped	D5572 - 31154
31/1	D5573	31155		Scrapped	D5573 - 31155
31/1	D5574	31156		Scrapped	D5574 - 31156
31/5	D5575	31157	31424 31524	Scrapped	D5575 - 31157 - 31424 - 31524
31/1	D5576	31158		Scrapped	D5576 - 31158
31/1	D5577	31159		Scrapped	D5577 - 31159
31/1	D5578	31160		Scrapped	D5578 - 31160
31/4	D5579	31161	31400	Scrapped	D5579 - 31161 - 31400
31/1	D5580	31162		Preservation	D5580 - 31162
31/1	D5581	31163		Preservation	D5581 - 31163
31/1	D5582	31164		Scrapped	D5582 - 31164
31/1	D5583	31165		Scrapped	D5583 - 31165
31/1	D5584	31166		Scrapped	D5584 - 31166
31/1	D5585	31167		Scrapped	D5585 - 31167
31/1	D5586	31168		Scrapped	D5586 - 31168
31/4	D5587	31169	31457	Scrapped	D5587 - 31169 - 31457
31/1	D5588	31170		Scrapped	D5588 - 31170
31/4	D5589	31401		Scrapped	D5589 - 31401
31/1	D5590	31171		Scrapped	D5590 - 31171
31/4	D5591	31172	31420	Scrapped	D5591 - 31172 - 31420
31/4	D5592	31402		Scrapped	D5592 - 31402
31/1	D5593	31173		Scrapped	D5593 - 31173
31/1	D5594	31174		Scrapped	D5594 - 31174
31/1	D5595	31175		Scrapped	D5595 - 31175
31/4	D5596	31403		Scrapped	D5596 - 31403
31/1	D5597	31176		Scrapped	D5597 - 31176
31/4	D5598	31177	31443	Scrapped	D5598 - 31177 - 31443
31/1	D5599	31178		Scrapped	D5599 - 31178
31/4	D5600	31179	31435	Preservation	D5600 - 31179 - 31435
31/1	D5601	31180		Scrapped	D5601 - 31180
31/1	D5602	31181		Scrapped	D5602 - 31181
31/4	D5603	31182	31537 31437	Scrapped	D5603 - 31182 - 31537 - 31437
31/1	D5604	31183		Scrapped	D5604 - 31183
31/4	D5605	31404		Scrapped	D5605 - 31404
31/4	D5606	31405		Scrapped	D5606 - 31405
31/1	D5607	31184		Scrapped	D5607 - 31184
31/1	D5608	31185		Scrapped	D5608 - 31185
31/6	D5609	31186	31601	Preservation	D5609 - 31186 - 31601
31/1	D5610	31187		Scrapped	D5610 - 31187
31/1	D5611	31188		Scrapped	D5611 - 31188
31/1	D5612	31189		Scrapped	D5612 - 31189
31/1	D5613	31190		Preservation	D5613 - 31190
31/6	D5614	31191	31602	Scrapped	D5614 - 31191 - 31602
31/1	D5615	31192		Scrapped	D5615 - 31192
31/4	D5616	31406		Scrapped	D5616 - 31406
31/4	D5617	31193	31526 31426	Scrapped	D5617 - 31193 - 31526 - 31426
31/4	D5618	31194	31427	Scrapped	D5618 - 31194 - 31427
31/1	D5619	31195		Scrapped	D5619 - 31195
31/1	D5620	31196		Scrapped	D5620 - 31196
31/4	D5621	31197	31423	Scrapped	D5621 - 31197 - 31423
31/1	D5622	31198		Scrapped	D5622 - 31198
31/1	D5623	31199		Scrapped	D5623 - 31199
31/1	D5624	31200		Scrapped	D5624 - 31200
31/1	D5625	31201		Scrapped	D5625 - 31201
31/1	D5626	31202		Scrapped	D5626 - 31202
31/1	D5627	31203		Preservation	D5627 - 31203
31/4	D5628	31204	31440	Scrapped	D5628 - 31204 - 31440
31/1	D5629	31205		Scrapped	D5629 - 31205
31/1	D5630	31206		Preservation	D5630 - 31206
31/1	D5631	31207		Preservation	D5631 - 31207
31/1	D5632	31208		Scrapped	D5632 - 31208
31/1	D5633	31209		Scrapped	D5633 - 31209
31/1	D5634	31210		Preservation	D5634 - 31210
31/4	D5635	31211	31428	Scrapped	D5635 - 31211 - 31428
31/1	D5636	31212		Scrapped	D5636 - 31212
31/4	D5637	31213	31565 31465	Preservation	D5637 - 31213 - 31565 - 31465
31/1	D5638	31214		Scrapped	D5638 - 31214
31/1	D5639	31215		Scrapped	D5639 - 31215
31/4	D5640	31507	31407	Scrapped	D5640 - 31507 - 31407
31/4	D5641	31216	31467	Scrapped	D5641 - 31216 - 31467
31/1	D5642	31217		Scrapped	D5642 - 31217
31/1	D5643	31218		Scrapped	D5643 - 31218
31/1	D5644	31219		Scrapped	D5644 - 31219
31/5	D5645	31220	31441 31541	Scrapped	D5645 - 31220 - 31441 - 31541
31/4	D5646	31408		Scrapped	D5646 - 31408
31/1	D5647	31221		Scrapped	D5647 - 31221
31/1	D5648	31222		Scrapped	D5648 - 31222
31/1	D5649	31223		Scrapped	D5649 - 31223
31/1	D5650	31224		Scrapped	D5650 - 31224
31/1	D5651	31225		Scrapped	D5651 - 31225
31/1	D5652	31226		Scrapped	D5652 - 312206
31/1	D5653	31227		Scrapped	D5653 - 31227
31/4	D5654	31228	31554 31454	Preservation	D5654 - 31228 - 31554 - 31454
31/1	D5655	31229		Scrapped	D5655 - 31229
31/4	D5656	31409		Scrapped	D5656 - 31409
31/1	D5657	31230		Scrapped	D5657 - 31230
31/1	D5658	31231		Scrapped	D5658 - 31231
31/1	D5659	31232		Scrapped	D5659 - 31232
31/1	D5660	31233		Preservation	D5660 - 31233
31/1	D5661	31234		Scrapped	D5661 - 31234
31/1	D5662	31235		Preservation	D5662 - 31235
31/4	D5663	31236	31533 31433	Scrapped	D5663 - 31236 - 31533 - 31433
31/1	D5664	31237		Scrapped	D5664 - 31237
31/1	D5665	31238		Scrapped	D5665 - 31238
31/4	D5666	31239	31439	Scrapped	D5666 - 31239 - 31439
31/1	D5667	31240		Scrapped	D5667 - 31240
31/1	D5668	31241		Scrapped	D5668 - 31241
31/4	D5669	31410		Scrapped	D5669 - 31410
31/1	D5670	31242		Scrapped	D5670 - 31242
31/1	D5671	31243		Scrapped	D5671 - 31243
31/1	D5672	31244		Scrapped	D5672 - 31244
31/1	D5673	31245		Scrapped	D5673 - 31245
31/4	D5674	31246	31555 31455	Scrapped	D5674 - 31246 - 31555- 31455
31/1	D5675	31247		Scrapped	D5675 - 31247
31/1	D5676	31248		Scrapped	D5676 - 31248
31/1	D5677	31249		Scrapped	D5677 - 31249
31/1	D5678	31250		Scrapped	D5678 - 31250
31/4	D5679	31251	31442	Scrapped	D5679 - 31251 - 31442
31/1	D5680	31252		Scrapped	D5680 - 31252
31/5	D5681	31253	31431 31531	Scrapped	D5681 - 31253 - 31431 - 31531
31/1	D5682	31254		Scrapped	D5682 - 31254
31/1	D5683	31255		Preservation	D5683 - 31255
31/4	D5684	31256	31459	Preservation	D5684 - 31256 - 31459
31/1	D5685	31257		Scrapped	D5685 - 31257
31/4	D5686	31258	31434	Scrapped	D5686 - 31258 - 31434
31/1	D5687	31259		Scrapped	D5687 - 31259
31/1	D5688	31260		Scrapped	D5688 - 31260
31/1	D5689	31261		Scrapped	D5689 - 31261
31/1	D5690	31262		Scrapped	D5690 - 31262
31/4	D5691	31511	31411	Scrapped	D5691 - 31511 - 31411
31/4	D5692	31512	31412	Scrapped	D5692 - 31512 - 31412
31/1	D5693	31263		Scrapped	D5693 - 31263
31/1	D5694	31264		Scrapped	D5694 - 31264
31/5	D5695	31265	31430 31530	Preservation	D5695 - 31265 - 31430 - 31530
31/4	D5696	31266	31460	Scrapped	D5696 - 31266 - 31460
31/5	D5697	31419	31519	Scrapped	D5697 - 31419 - 31519
31/1	D5698	31268		Scrapped	D5698 - 31268
31/4	D5699	31269	31429	Scrapped	D5699 - 31269 - 31429
31/1	D5800	31270		Preservation	D5800 - 31270
31/1	D5801	31271		Preservation	D5801 - 31271
31/1	D5802	31272		Scrapped	D5802 - 31272
31/1	D5803	31273		Scrapped	D5803 - 31273
31/4	D5804	31274	31425	Scrapped	D5804 - 31274 - 31425
31/1	D5805	31275		Scrapped	D5805 - 31275
31/1	D5806	31276		Scrapped	D5806 - 31276
31/5	D5807	31277	31469 31569	Scrapped	D5807 - 31277 - 31469 - 31569
31/1	D5808	31278		Scrapped	D5808 - 31278
31/4	D5809	31279	31552 31452	Preservation	D5809 - 31279 - 31552 - 31452
31/1	D5810	31280		Scrapped	D5810 - 31280
31/1	D5811	31281		Scrapped	D5811 - 31281
31/4	D5812	31413		Scrapped	D5812 - 31413
31/1	D5813	31282		Scrapped	D5813 - 31282
31/5	D5814	31414	31514	Preservation	D5814 - 31414 - 31514
31/1	D5815	31283		Scrapped	D5815 - 31283
31/1	D5816	31284		Scrapped	D5816 - 31284
31/1	D5817	31285		Preservation	D5817 - 31285
31/1	D5818	31286		Scrapped	D5818 - 31286
31/1	D5819	31287		Scrapped	D5819 - 31287
31/1	D5820	31288		Scrapped	D5820 - 31288
31/1	D5821	31289		Preservation	D5821 - 31289
31/1	D5822	31290		Scrapped	D5822 - 31290
31/5	D5823	31291	31456 31556	Scrapped	D5823 - 31291 - 31456 - 31556
31/4	D5824	31415		Scrapped	D5824 - 31415
31/1	D5825	31292		Scrapped	D5825 - 31292
31/1	D5826	31293		Scrapped	D5826 - 31293
31/1	D5827	31294		Scrapped	D5827 - 31294
31/5	D5828	31295	31447 31547	Scrapped	D5828 - 31295 - 31447 - 31547
31/1	D5829	31296		Scrapped	D5829 - 31296
31/5	D5830	31297	31463 31563	Preservation	D5830 - 31297 - 31463 - 31563
31/1	D5831	31298		Scrapped	D5831 - 31298
31/1	D5832	31299		Scrapped	D5832 - 31299
31/5	D5833	31300	31445 31545	Scrapped	D5833 - 31300 - 31445 - 31545
31/1	D5834	31301		Scrapped	D5834 - 31301
31/1	D5835	31302		Scrapped	D5835 - 31302
31/5	D5836	31303	31458 31558	Scrapped	D5836 - 31303 - 31458 - 31558
31/1	D5837	31304		Scrapped	D5837 - 31304
31/1	D5838	31305		Scrapped	D5838 - 31305
31/1	D5839	31306		Scrapped	D5839 - 31306
31/5	D5840	31307	31449 31549	Scrapped	D5840 - 31307 - 31449 - 31549
31/1	D5841	31308		Scrapped	D5841 - 31308
31/5	D5842	31416	31516	Scrapped	D5842 - 31416 - 31516
31/1	D5843	31309		Scrapped	D5843 - 31309
31/4	D5844	31310	31522 31422	Scrapped	D5844 - 31310 - 31522 - 31422
31/1	D5845	31311		Scrapped	D5845 - 31311
31/1	D5846	31312		Scrapped	D5846 - 31312
31/1	D5847	31313		Scrapped	D5847 - 31313
31/1	D5848	31314		Scrapped	D5848 - 31314
31/4	D5849	31315	31462	Scrapped	D5849 - 31315 - 31462
31/5	D5850	31316	31446 31546	Scrapped	D5850 - 31316 - 31446 - 31546
31/1	D5851	31317		Scrapped	D5851 - 31317
31/5	D5852	31318	31451 31551	Scrapped	D5852 - 31318 - 31451 - 31551
31/1	D5853	31319		Scrapped	D5853 - 31319
31/1	D5854	31320		Scrapped	D5854 - 31320
31/4	D5855	31321	31568 31468	Scrapped	D5855 - 31321 - 31568 - 31468
31/4	D5856	31417		Scrapped	D5856 - 31417
31/1	D5857	31322		Scrapped	D5857 - 31322
31/1	D5858	31323		Scrapped	D5858 - 31328
31/1	D5859	31324		Scrapped	D5859 - 31324
31/4	D5860	31325	31464	Scrapped	D5860 - 31325 - 31464
31/1	D5861	31326	31970	Scrapped	D5861 - 31326 - 31970
31/1	D5862	31327		Preservation	D5862 - 31327
