SPECIFICATIONS
| POWER TYPE | Diesel Electric |
| BUILDER | Metropolitan Vickers, Stockton |
| WHEEL ARRANGEMENT | Co-Bo |
| WHEELBASE | 42 ft 7in |
| DIMENSIONS | L. -56ft 7.5in W. - 9ft 2.5in H.-12ft 8.5in |
| WEIGHT | 97 ton |
| WHEEL DIAMETER | 3ft 3.5in |
| ENGINE | Crossley HSTV8 |
| TRACTIVE EFFORT | 50,000lbs |
| TRAIN BRAKES | Vacuum |
| BRAKE FORCE | 35 tonnes |
| FUEL CAPACITY | 510 gals |
| POWER OUTPUT | 1200hp |
| MAX SPEED | 75mph |
| BUILT/ WITHDRAWN | 1958-59 / 1967-77 | No. BUILT | 20 |
RETURN TO LIST OF CLASS TYPES
RETURN TO LIST OF LOCO NUMBERS
LOCOMOTIVES IN CLASS
| REGION OR CLASS |
REGION No. |
1948 No. | 1957 No. | TOPS No. | RENUMBER | STATUS | LOCO FACTS |
|---|---|---|---|---|---|---|---|
| 28 | D5700 | Scrapped | D5700 | ||||
| 28 | D5701 | Scrapped | D5701 | ||||
| 28 | D5702 | Scrapped | D5702 | ||||
| 28 | D5703 | Scrapped | D5703 | ||||
| 28 | D5704 | Scrapped | D5704 | ||||
| 28 | D5705 | Preservation | D5705 | ||||
| 28 | D5706 | Scrapped | D5706 | ||||
| 28 | D5707 | Scrapped | D5707 | ||||
| 28 | D5708 | Scrapped | D5708 | ||||
| 28 | D5709 | Scrapped | D5709 | ||||
| 28 | D5710 | Scrapped | D5710 | ||||
| 28 | D5711 | Scrapped | D5711 | ||||
| 28 | D5712 | Scrapped | D5712 | ||||
| 28 | D5713 | Scrapped | D5713 | ||||
| 28 | D5714 | Scrapped | D5714 | ||||
| 28 | D5715 | Scrapped | D5715 | ||||
| 28 | D5716 | Scrapped | D5716 | ||||
| 28 | D5717 | Scrapped | D5717 | ||||
| 28 | D5718 | Scrapped | D5718 | ||||
| 28 | D5719 | Scrapped | D5719 |
