SPECIFICATIONS
| POWER TYPE | Diesel Electric |
| BUILDER | Birmingham Railway Carriage & Wagon Co. |
| WHEEL ARRANGEMENT | Bo-Bo |
| WHEELBASE | 39ft |
| DIMENSIONS | L. 50ft 9in W.8ft 10in H.12ft 8in |
| WEIGHT | 74-77 tonnes |
| WHEEL DIAMETER | 3ft 7in |
| ENGINE | Sulzer 6LDA28B |
| TRACTIVE EFFORT | 40000lb |
| TRAIN BRAKES | Vacuum then Dual |
| BRAKE FORCE | 35 tonnes |
| FUEL CAPACITY | 970gal |
| POWER OUTPUT | 1250hp |
| MAX SPEED | |
| BUILT/ WITHDRAWN | 1961-62 / 1975-89 | No. BUILT | 69 |
SUB CLASSES
| 27/0 | Original Specification |
| 27/1 | Converted to Push Pull operations with Steam Heat (27101-118) and Electric Heat(27119-24) steam heat locos renumberd back to 27/0 on removal of Push-Pull, but most electric ones to Class 27/2 |
| 27/2 | Train Heating - Electric |
RETURN TO LIST OF CLASS TYPES
RETURN TO LIST OF LOCO NUMBERS
LOCOMOTIVES IN CLASS
| REGION OR CLASS |
REGION No. |
1948 No. | 1957 No. | TOPS No. | RENUMBER | STATUS | LOCO FACTS |
|---|---|---|---|---|---|---|---|
| 27/0 | D5347 | 27001 | Preservation | D5347 - 27001 | |||
| 27/0 | D5348 | 27002 | Scrapped | D5348 - 27002 | |||
| 27/0 | D5349 | 27003 | Scrapped | D5349 - 27003 | |||
| 27/0 | D5350 | 27004 | Scrapped | D5350 - 27004 | |||
| 27/0 | D5351 | 27005 | Preservation | D5351 - 27005 | |||
| 27/0 | D5352 | 27006 | Scrapped | D5352 - 27006 | |||
| 27/0 | D5353 | 27007 | Preservation | D5353 - 27007 | |||
| 27/0 | D5354 | 27008 | Scrapped | D5354 - 27008 | |||
| 27/0 | D5355 | 27009 | Scrapped | D5355 - 27009 | |||
| 27/0 | D5356 | 27010 | Scrapped | D5356 - 27010 | |||
| 27/0 | D5357 | 27011 | Scrapped | D5357 - 27011 | |||
| 27/0 | D5358 | 27012 | Scrapped | D5358 - 27012 | |||
| 27/0 | D5359 | 27013 | Scrapped | D5359 - 27013 | |||
| 27/0 | D5360 | 27014 | Scrapped | D5360 - 27014 | |||
| 27/0 | D5361 | 27015 | Scrapped | D5361 - 27015 | |||
| 27/0 | D5362 | 27016 | Scrapped | D5362 - 27016 | |||
| 27/0 | D5363 | 27017 | Scrapped | D5363 - 27017 | |||
| 27/0 | D5364 | 27018 | Scrapped | D5364 - 27018 | |||
| 27/0 | D5365 | 27019 | Scrapped | D5365 - 27019 | |||
| 27/0 | D5366 | 27020 | Scrapped | D5366 - 27020 | |||
| 27/0 | D5367 | 27021 | Scrapped | D5367 - 27021 | |||
| 27/0 | D5368 | 27022 | Scrapped | D5368 - 27022 | |||
| 27/0 | D5369 | 27023 | Scrapped | D5369 - 27023 | |||
| 27/0 | D5370 | 27024 | Preservation | D5370 - 27024 | |||
| 27/0 | D5371 | 27025 | Scrapped | D5371 - 27025 | |||
| 27/0 | D5372 | 27026 | Scrapped | D5372 - 27026 | |||
| 27/0 | D5373 | 27027 | Scrapped | D5373 - 27027 | |||
| 27/0 | D5374 | 27045 | 27101 27045 |
Scrapped | D5374 - 27101 - 27045 | ||
| 27/0 | D5375 | 27028 | Scrapped | D5375 - 27028 | |||
| 27/0 | D5376 | 27029 | Scrapped | D5376 - 27029 | |||
| 27/0 | D5377 | 27030 | Scrapped | D5377 - 27030 | |||
| 27/0 | D5378 | 27031 | Scrapped | D5378 - 27031 | |||
| 27/0 | D5379 | 27032 | Scrapped | D5379 - 27032 | |||
| 27/0 | D5380 | 27046 | 27102 27046 |
Scrapped | D5380 - 27046 - 27102 | ||
| 27/0 | D5381 | 27033 | Scrapped | D5381 - 27033 | |||
| 27/0 | D5382 | 27034 | Scrapped | D5382 - 27034 | |||
| 27/0 | D5383 | Scrapped | D5383 | ||||
| 27/0 | D5384 | 27035 | Scrapped | D5384 - 27035 | |||
| 27/0 | D5385 | 27036 | Scrapped | D5385 - 27036 | |||
| 27/0 | D5386 | 27066 | 27103 27212 |
Preservation | D5386 - 27066 - 27103 - 27212 | ||
| 27/0 | D5387 | 27048 | 27104 | Scrapped | D5387 - 27048 - 27104 | ||
| 27/0 | D5388 | 27049 | 27105 | Scrapped | D5388 - 27049 - 27105 | ||
| 27/0 | D5389 | 27037 | Scrapped | D5389 - 27037 | |||
| 27/0 | D5390 | 27038 | Scrapped | D5390 - 27038 | |||
| 27/2 | D5391 | 27119 | 27201 | Scrapped | D5391 - 27119 - 27201 | ||
| 27/2 | D5392 | 27120 | 27202 | Scrapped | D5392 - 27120 - 27202 | ||
| 27/2 | D5393 | 27121 | 27203 | Scrapped | D5393 - 27121 - 27203 | ||
| 27/0 | D5394 | 27050 | 27106 | Preservation | D5394 - 27050 - 27106 | ||
| 27/0 | D5395 | 27051 | 27107 | Scrapped | D5395 - 27051 - 27107 | ||
| 27/0 | D5396 | 27052 | 27108 | Scrapped | D5396 - 27052 - 27108 | ||
| 27/0 | D5397 | 27053 | 27109 | Scrapped | D5397 - 27053 - 27109 | ||
| 27/0 | D5398 | 27039 | Scrapped | D5398 - 27039 | |||
| 27/0 | D5399 | 27054 | 27110 | Scrapped | D5399 - 27054 - 27110 | ||
| 27/0 | D5400 | 27055 | 27111 | Scrapped | D5400 - 27055 - 27111 | ||
| 27/0 | D5401 | 27056 | 27112 | Preservation | D5401 - 27056 - 27112 | ||
| 27/0 | D5402 | 27040 | Scrapped | D5402 - 27040 | |||
| 27/0 | D5403 | 27058 | 27122 27204 |
Scrapped | D5403 - 27058 - 27122 - 27204 | ||
| 27/2 | D5404 | 27113 | 27207 | Scrapped | D5404 - 27113 - 27207 | ||
| 27/0 | D5405 | 27041 | Scrapped | D5405 - 27041 | |||
| 27/0 | D5406 | 27042 | Scrapped | D5406 - 27042 | |||
| 27/2 | D5407 | 27114 | 27208 | Scrapped | D5407 - 27114 - 27208 | ||
| 27/0 | D5408 | 27115 | 27209 27063 |
Scrapped | D5408 - 27115 - 27209 - 27063 | ||
| 27/0 | D5409 | 27116 | 27210 27064 |
Scrapped | D5409 - 27116 - 27210 - 27064 | ||
| 27/0 | D5410 | 27123 | 27205 27059 |
Preservation | D5410 - 27123 - 27205 - 27059 | ||
| 27/0 | D5411 | 27117 | 27211 27065 |
Scrapped | D5411 - 27117 - 27211 - 27065 | ||
| 27/2 | D5412 | 27124 | 27206 | Scrapped | D5412 - 27124 - 27206 | ||
| 27/0 | D5413 | 27118 | 27103 27047 |
Scrapped | D5413 - 27118 - 27103 - 27047 | ||
| 27/0 | D5414 | 27043 | Scrapped | D5414 - 27043 | |||
| 27/0 | D5415 | 27044 | Scrapped | D5415 - 27044 |
