SPECIFICATIONS
| POWER TYPE | Diesel Electric |
| BUILDER | English Electric, Vulcan Foundry, Newton Le Willows |
| WHEEL ARRANGEMENT | Bo-Bo |
| WHEELBASE | 40ft 6in |
| DIMENSIONS | L. -52ft 6in W. - 8ft 10.75in H.12ft 8in |
| WEIGHT | 74 ton |
| WHEEL DIAMETER | 3ft 7in |
| ENGINE | Deltic T9-29 |
| TRACTIVE EFFORT | 47000lb |
| TRAIN BRAKES | Vacuum |
| BRAKE FORCE | 36 tonnes |
| FUEL CAPACITY | 450 gals |
| POWER OUTPUT | 1100hp |
| MAX SPEED | 75mph |
| BUILT/ WITHDRAWN | 1959 / 1968-71 | No. BUILT | 10 |
RETURN TO LIST OF CLASS TYPES
RETURN TO LIST OF LOCO NUMBERS
LOCOMOTIVES IN CLASS
| REGION OR CLASS |
REGION No. |
1948 No. | 1957 No. | TOPS No. | RENUMBER | STATUS | LOCO FACTS |
|---|---|---|---|---|---|---|---|
| 23 | D5900 | Scrapped | D5900 | ||||
| 23 | D5901 | Scrapped | D5901 | ||||
| 23 | D5902 | Scrapped | D5902 | ||||
| 23 | D5903 | Scrapped | D5903 | ||||
| 23 | D5904 | Scrapped | D5904 | ||||
| 23 | D5905 | Scrapped | D5905 | ||||
| 23 | D5906 | Scrapped | D5906 | ||||
| 23 | D5907 | Scrapped | D5907 | ||||
| 23 | D5908 | Scrapped | D5908 | ||||
| 23 | D5909 | Scrapped | D5909 |
