SPECIFICATIONS
| POWER TYPE | Diesel Electric |
| BUILDER | North British Locomotive Co. |
| UIC WHEEL ARRANGEMENT | Bo-Bo |
| WHEELBASE | 28ft 6in |
| DIMENSIONS | L.42ft 6in - W.8ft 8.5in - H.12ft 8in |
| WEIGHT | 68 ton |
| WHEEL DIAMETER | 3ft 7in |
| ENGINE | Paxman 16YHXL |
| MAX TRACTIVE EFFORT | 42000lbf |
| TRAIN BRAKES | Vacuum |
| BRAKE FORCE | 31 ton |
| FUEL CAPACITY | 400 Gals |
| POWER OUTPUT | 800 hp |
| MAX SPEED | 60 mph |
| BUILT / WITHDRAWN | 1958 / 1968 | No. BUILT | 10 |
RETURN TO LIST OF CLASS TYPES
RETURN TO LIST OF LOCO NUMBERS
LOCOMOTIVES IN CLASS
| REGION OR CLASS |
REGION No. |
1948 No. | 1957 No. | TOPS No. | RENUMBER | STATUS | LOCO FACTS |
|---|---|---|---|---|---|---|---|
| 16 | D8400 | Scrapped | D8400 | ||||
| 16 | D8401 | Scrapped | D8401 | ||||
| 16 | D8402 | Scrapped | D8402 | ||||
| 16 | D8403 | Scrapped | D8403 | ||||
| 16 | D8404 | Scrapped | D8404 | ||||
| 16 | D8405 | Scrapped | D8405 | ||||
| 16 | D8406 | Scrapped | D8406 | ||||
| 16 | D8407 | Scrapped | D8407 | ||||
| 16 | D8408 | Scrapped | D8408 | ||||
| 16 | D8409 | Scrapped | D8409 |
